Main Specifications:

Model: QD70

Size: 680*630*980mm

Main material: SUS304/Al alloy

Cutting shape:Cubes

Cutting size: 3-25mm (Different sizes changed by different blade sets)

Power: 0.75kw

Voltage:220V/380V,50HZ/60HZ,(or others)

Capacity: 300-400kgs/hour

Warranty:One year

Model: QD90

Size: 890*710*1260mm

Main material: SUS304/Al alloy

Cutting shape:Cubes

Cutting size: 3-25mm (By changing different blade sets)

Power: 0.75kw

Voltage:380V,50HZ/60HZ,(or others)

Capacity: 500-800kgs/hour

Origin:Made in Taiwan

Introduction:

Three-dimensional fruit and vegetable dicer,or 3D vegetable fruit dicing machine, for cutting various root, stem vegetables and fruits into the cube or cuboid shape.Suitable for dehydrated vegetables fruits, quick frozen vegetables fruits and pickles industries.

Advantages: The machine adopts compound cutter which is formed in one time, with regular shape, and smooth section. The design is easy to operate, low energy consumption, and high efficiency. The main materials are aluminum magnesium alloy and stainless steel materials, which are anti-corrosion, beautiful, and meet the sanitary standards.

The feeding port is enlarged, so the operation is more convenient, which is suitable for the complete production line.

Dicing specification:

This machine can cut all kinds of stems, root vegetables, and fruits, etc. into 3, 4, 5, 6, 8, 10, 12, 15, 20, 25mm cube or cuboid shape, and can also customize special sizes according to requirements.
